DB9 FEMALE TO 3.5MM SERIAL CABLE 6 FEET

OrderQtyDescription
DB9-Female to 3.5mm Serial Cable 6 Feet
DB9-Female to 3.5mm Serial Cable 6 Feet

6 Foot DB9-Female to 3.5mm TRS Connector Male

Generic Serial Transfer Cable For Devices
Stereo 3.5 mm Jack.
to DB9-F Serial Port.
Primarily used to transfer Serial Data back and forth from Small devices.
TRS_Male_Connector
DB9_Female_Connector
Wiring Schematic
DB9-F         TRS Connector 3.5mm
Pin 1-6-7-8
Pin 2         Tip  - Left
Pin 3         Ring - Right
Pin 4
Pin 5         Sleeve - Shield - Ground
Pin 9
Shell         Sleeve - Shield - Ground
Some Compatible Part Numbers.
SAMSUNG Compatible Part# AA39-00311A
Commonly Called an Exlink Cable.
Similar to Vaster: 20212

Compatible Devices

CAMERA

CASIO

  1. QV-10
  2. QV-100
  3. QV-10A
  4. QV-11
  5. QV-120
  6. QV-200
  7. QV-200 Plus
  8. QV-2000
  9. QV-2000U
  10. QV-2300
  11. QV-2800
  12. QV-30
  13. QV-300
  14. QV-5500SX
  15. QV-70
  16. QV-700
  17. QV-7000SX
  18. QV-770
  19. QV-780
  20. SB155
