HDMI HDCP to SVGA CONVERTER with Audio

Part No85507
StockUNAVAILABLE DISCONTINUED
UPC Code
HDMI HDCP to SVGA CONVERTER with Audio

HDMI to VGA Converter

The Converter use a single HDMI source, accessing to single VGA + SPDIF sink or single YPbPr + SPDIF sink. This converter allows one HDMI device to be converted easily to one VGA + SPIDF or one YPbPr + SPIDF/(R + L) monitor or projector. Our devices offers solutions for noise, space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.



* One HDMI input signal convert to one YPbPr + SPDIF + R/L or VGA + SPDIF sink device

* Supports video input: HDMI 1.2a

* Supports audio output: SPDIF (optical) + R/L analog

* Supports output: up to UXGA and 1080p (50/60Hz), the same format as input

* HDCP 1.2 protocol compliant

* LED indication: when source or sink is working, LED relative to is light

* No loss of quality

* Installs in minutes

* INCLUDES 5V DC/0.8A power supply



* Connect one cable from HDMI 1.2 sink into the converter input

* Connect VGA + SPDIF or YPbPr + SPDIF from monitor or projector into converter output

* Connect 5V power supply to the HDCRBG0102 converter



* HDMI resolution: 1.2a

* Input video signal: 0.5 to 1.5Vp-p

* Input DDC signal: 5Vp-p (TTL)

* VGA or YPbPr output: supports up to UXGA and 1080p (60Hz)

* Audio output: R/L analog and optical

* Maximum transmission bandwidth: 5.1Gbps

* Maximum working current: 600mA

* Power adapter formats:

* Input: 100 to 240V AC (50Hz, 60Hz)

* Output: 5V DC/0.8A

* Operating temperature range: -15 to +55C

* Operating humidity range: 5 to 90% RH (no condensation)

* Dimension (L x W x H): 174 x 70 x 20mm

* Weight: 750g
